Parameters：

Two parameters：SPO2, Pulse Rate.

Waveforms:

SpO2 Waveform

Features：

1. 64k COLOR OLED Display, Four Direction adjustable

2. SpO2 and pulse monitoring, and Waveform display

3. Easy to use with one-key operation

4. Small in size, and easy to carry

5. Low voltage alarm display, Auto power-off

6. Runs on standard AAA batteries

Dimension: 67x 38x 36mm

Net Weight: 65g (include batteries)

Gross Weight: 0.15kg

Package Size: 130x 75x 45mm

Color: White

Specifications:

SpO2:

Measurement range: 35~100%

Accuracy: +/-2% (70~100%), 0~69% unspecified

Resolution: 1%

Pulse Rate:

Measurement range: 30~250 bpm

Accuracy: +/-2 bpm

Resolution: 1bpm

Display Mode: 64k COLOR OLED Display, Four Direction adjustable

Battery type: Two common 1.5V AAA alkaline or rechargeable batteries

Environment Requirements

Temperature:

Working:     0 ~ 40°C

Transport and storage:   -20 °C ~ 60 °C

Humidity:

Working:     15 ~ 95 %( non-condensing)

Transport and storage: 10 ~ 95 %( non-condensing)

Altitude:

Working:        86 KPa ~ 106 Kpa

Transport and storage:   50KPa ~ 106 Kpa
